Light Assembly
The unit uses 40 watt bulbs to light the unit. The
bulbs are located at the top of unit.
To access bulbs, remove light cover and bulb is
accessible.
To check bulb, verify filament is not broken,
resistance in the bulb, and voltage is supplied to
the socket.
Fresh Food Fan Assembly
The unit uses a fan to circulate air through the
refrigerator compartment.
1. To access, remove shelves, remove covers in
upper left and right rear corners.
2. Remove screws securing cover.
3. Disconnect wiring and fan is accessible.
Fan measures approximately 100M Ω, 3.2 W.
4. Reverse procedure to reinstall.
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power to unit using power
switch before servicing. Wires removed during disassembly must be replaced on proper terminals to insure
correct earth ground and polarization. After servicing, reconnect power using power switch.
Bulbs
Corner Covers
Corner Screws
Fresh Food Fan
