Operation
©2012 Viking Preferred Service 13
4. Using a 5/16” head wrench, turn the rear
(R) adjustment screws to raise or lower
the rear of the refrigerator.
5. Reinstall kickplate.
Note: DO NOT use an electric device.
Overtightening can cause damage.
Height Adjustment
Removal of the kickplate allows access
to rollers and stabilizing legs for height
adjustment.
1. Remove lower kickplate screws using a
Phillips screwdriver.
2. Remove upper kickplate screws using a
Phillips screwdriver. Remove kickplate
assembly.
3. Using a 5/16” head wrench, turn the front
(F) adjustment screws to raise or lower
the front of the freezer.
Note: DO NOT use an electric device.
Overtightening can cause damage.
