10.5. SINGLE LEAF learning procedure WITH deceleration.
1. Begin the procedure with the gate closed.
2. Press push button P1 and hold it down. LED DL7 starts to ash (1
st
ashing frequency).
3. Do not release push button P1. The ashing becomes faster (2
nd
ashing sequence).
4. Do not release push button P1 until it ashes faster (3
nd
ashing frequency).
5. Release push button P1.
6. Follow the programming phases shown in the gure.
7. Programming ends when LED DL7 stops ashing.
CAUTION: After resetting or powering the board, the travel time of the rst closing manoeuvre increases by approximately 5 seconds to allow the
completion of motion in any case.
1
st
START
The rst START begins the
learning process by moving
MOTOR 1 in opening
(Caution! start with the
gate closed)
4
th
START
DECEL.ZONE CL. M1
The fourth START sets the
starting point of MOTOR 1
closing deceleration
2
nd
START
DECEL.ZONE OP. M1
The second START
sets the starting point
of MOTOR 1 opening
deceleration
5
th
START
The fth START sets the
MOTOR 1 travel end and
should be pressed when
leaf 1 reaches the stop
3
rd
START
The third START sets the
MOTOR 1 travel end and
should be pressed when
leaf 1 reaches the stop
To complete programming,
wait for the gate to be
completely closed and LED
DL7 to be o󰀨
10.6. SINGLE LEAF learning procedure WITHOUT deceleration.
1. Begin the procedure with the gate closed.
2. Adjust trimmer TR3 SL to the maximum setting (complete clockwise rotation), thereby excluding deceleration.
3. Press push button P1 and hold it down. LED DL7 starts to ash (1
st
ashing frequency).
4. Do not release push button P1. The ashing becomes faster (2
nd
ashing sequence).
5. Do not release push button P1 until it ashes faster (3
nd
ashing frequency).
6. Release push button P1.
7. Follow the programming phases shown in the gure.
8. Programming ends when LED DL7 stops ashing.
CAUTION: After resetting or powering the board, the travel time of the rst closing manoeuvre increases by approximately 5 seconds to allow the
completion of motion in any case.
1
st
START
The rst START begins the
learning process by moving
MOTOR 1 in opening
(Caution! start with the
gate closed)
3
rd
START
The third START sets the
MOTOR 1 travel end and
should be pressed when
leaf 1 reaches the stop
2
nd
START
The second START sets
the MOTOR 1 travel end
and should be pressed
when leaf 1 reaches the
stop
To complete programming,
wait for the gate to be
completely closed and LED
DL7 to be o󰀨
