14. Troubleshooting.
Problem Cause Solution
The automatic gate sys-
tem does not work
No mains supply Check the power line switch
Blown fuses Replace the fuses with others of the same value
Control and safety inputs not
working
Check the diagnostics LEDs: DL2 STOP, DL4 SCL, DL5 SOP must be on.
Safety device test failed Check the operation of the safety devices installed if 4 simultaneous ashes of the
following occur: LED DL7, indicator light and ashing lamp.
Triac operating control test failed Replace the control unit if 2 simultaneous ashes of the following occur: LED DL7,
indicator light and ashing lamp.
You cannot save the
remote controls
Batteries of the remote control
discharged
Replace the batteries
Remote control not compatible with
the rst one saved
The rst saved rolling-code remote control congures the control unit to save only
rolling-code remote controls and not hard coded remote controls.
Reached memory saturation Delete at least one remote control or add an external receiver (maximum capacity
128 remote controls)
The remote control does
not work
Batteries of the remote control
discharged
Replace the batteries
You cannot enter travel
programming
Safety devices open Check the diagnostics LEDs: DL2 STOP, DL4 SCL, DL5 SOP must be on.
As soon as the gate
starts it stops and re-
verses
Low acceleration on starting Increase the TR2 TORQ trimmer
During slowdown, the
gate stops and reverses
Slowdown speed too low Increase the TR2 TORQ trimmer
