Chapter 5 Deployment I/O periphery Manual VIPA System 300S SPEED7
5-34 HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45
The record set 1 contains the 4Byte of the record set 0 and additionally
12Byte module specific diagnostic data.
The diagnostic bytes have the following assignment:
Byte Bit 7 ... 0
0 ... 3 Contents record set 0 (see page before)
4 Bit 6 ... 0: channel type (here 70h)
70h: Digital input
71h: Analog input
72h: Digital output
73h: Analog output
74h: Analog in-/output
Bit 7: More channel types present
0: no
1: yes
5 Number of diagnostic bits per channel (here 08h)
6 Number of channels of a module (here 08h)
7 Bit 0: Error in channel group 0 (I+0.0 ... I+0.3)
Bit 1: Error in channel group 1 (I+0.4 ... I+0.7)
Bit 2: Error in channel group 2 (I+1.0 ... I+1.3)
Bit 3: Error in channel group 3 (I+1.4 ... I+I.7)
Bit 4: Error in channel group 4 (Counter 0)
Bit 5: Error in channel group 5 (Counter 1)
Bit 6: Error in channel group 6 (Counter 2)
Bit 7: reserviert
8 Diagnostic interrupt due to hardware interrupt lost at...
Bit 0: ... input I+0.0
Bit 1: 0 (fix)
Bit 2: ... input I+0.1
Bit 3: 0 (fix)
Bit 4: ... input I+0.2
Bit 5: 0 (fix)
Bit 6: ... input I+0.3
Bit 7: 0 (fix)
9 Diagnostic interrupt due to hardware interrupt lost at...
Bit 0: ... input I+0.4
Bit 1: 0 (fix)
Bit 2: ... input I+0.5
Bit 3: 0 (fix)
Bit 4: ... input I+0.6
Bit 5: 0 (fix)
Bit 6: ... input I+0.7
Bit 7: 0 (fix)
10
Diagnostic interrupt due to hardware interrupt lost at...
Bit 0: ... input I+1.0
Bit 1: 0 (fix)
Bit 2: ... input I+1.1
Bit 3: 0 (fix)
Bit 4: ... input I+1.2
Bit 5: 0 (fix)
Bit 6: ... input I+1.3
Bit 7: 0 (fix)
continued ...
Diagnostic
Record set 1
(Byte 0 ... 15)
