VIPA System 300S SPEED7 CPU 313SC/DPM User Manual

Manual VIPA System 300S SPEED7 Chapter 5 Deployment I/O periphery
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 5-35
... continue Record set 1
Byte Bit 7 ... 0
11 Diagnostic interrupt due to hardware interrupt lost at...
Bit 0: ... input I+1.4
Bit 1: 0 (fix)
Bit 2: ... input I+1.5
Bit 3: 0 (fix)
Bit 4: ... input I+1.6
Bit 5: 0 (fix)
Bit 6: ... input I+1.7
Bit 7: 0 (fix)
12 Diagnostic interrupt due to hardware interrupt lost at...
Bit 0: ... Gate Counter 0 closed
Bit 1: 0 (fix)
Bit 2: ... Gate Counter 0 open
Bit 3: 0 (fix)
Bit 4: ... Over-/underflow/end value Counter 0
Bit 5: 0 (fix)
Bit 6: ... Counter 0 reached comparison value
Bit 7: 0 (fix)
13 Diagnostic interrupt due to hardware interrupt lost at...
Bit 0: ... Gate Counter 1 closed
Bit 1: 0 (fix)
Bit 2: ... Gate Counter 1 open
Bit 3: 0 (fix)
Bit 4: ... Over-/underflow/end value Counter 1
Bit 5: 0 (fix)
Bit 6: ... Counter 1 reached comparison value
Bit 7: 0 (fix)
14 Diagnostic interrupt due to hardware interrupt lost at...
Bit 0: ... Gate Counter 2 closed
Bit 1: 0 (fix)
Bit 2: ... Gate Counter 2 open
Bit 3: 0 (fix)
Bit 4: ... Over-/underflow/end value Counter 2
Bit 5: 0 (fix)
Bit 6: ... Counter 2 reached comparison value
Bit 7: 0 (fix)
15 reserved
