Digital Output 313-6CF03
Data for specific module
Number of outputs 16
Length of cable
- unshielded 600m
- shielded 1000m
Voltages, Currents, Potentials
Rated load voltage L+ DC 24V
Reverse polarity protection no
Total current of the outputs
- horizontal configuration up to 40°C 3A
- horizontal configuration up to 60°C 2A
- vertical configuration up to 40°C 2A
Isolation
- Between the channels and backplane bus yes
- Between the channels no
in groups of 8 yes
Permitted potential difference
- between the different circuits DC 75V / AC 60V
Insulation tested with DC 500V
Current consumption
- from load voltage L+ 100mA
Status, Interrupts, Diagnostics
Status display green LED per channel
Interrupts none
Diagnostic functions
- Group error display red F-LED per group
- supply voltage display green LED per group
- Channel error display none
Data for selecting an actuator
Output voltage
- for Signal "1" min. L+ (-0.8V)
Output current
- at Signal "1" 0.5A
Rated value 5mA to 0.6A
- at Signal "0" 0.5mA
Load resistor range
48Ω to 4kΩ
Lamp load 5W
Parallel connection of 2 outputs
- for redundant triggering of a load possible
- to increase performance not possible
Actuation of digital input possible
Switch rate
- for resistive load 2.5kHz
- for inductive load (IEC 947-5 DC 13) 0.5Hz
- for lamp load 2.5kHz
Limitation (internal) voltage induced on circuit
interruption at typ. L+ (-52V)
Short-circuit protection of the outputs yes, electronic
- Threshold on typ. 1A
