Chapter 3 Hardware description Manual VIPA System 300S SPEED7
3-12 HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45
... continue
Integrated functions
Number of counters 3
- Counter frequency max. 30kHz
Programming
Programming language KOP/FUP/AWL
Instruction set see the instruction list
Nesting levels 8
System functions (SFC) see the instruction list
System function blocks (SFB) see the instruction list
User program protection yes
Digital Input 313-6CF03
Data for specific module
Number of inputs 16
Length of cable
- unshielded 600m
- shielded 1000m
Voltages, Currents, Potentials
Rated load voltage L+ DC 24V
Reverse polarity protection yes
Isolation
- between channels and backplane bus yes
- between channels no
permitted potential difference
- between the different circuits DC 75V / AC 60V
Isolation tested with DC 500V
Current consumption
- from the power supply L+ 70mA
Status, Interrupts, Diagnostics
Status display green LED per channel
Interrupts none
Diagnostic functions none
Data for selecting a Sensor
Input voltage
- Rated value DC 24V
- for Signal "1" 15V to 28.8V
- for Signal "0" 0V to 5V
Input current
- for Signal "1" 6mA
Input delay
(at nominal value of the input voltage range)
- Inputs parameterizable 0.1ms-0.35ms
Input characteristic curve according to IEC 1131, Type 1
Connection of 2-wire-BEROs possible
- permitted bias current max. 1.5mA
continued ...
