Manual VIPA System 300S SPEED7 Chapter 3 Hardware description
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 3-11
... continue
Module name 313-6CF03
Communication functions
PG/OP communication yes
Global Data communication yes
- Number of GD circuit 4
- Number of GD circuit 4
Sending stations 4
Receiving stations 4
- Length of GD packets 22Byte
S7 basic communication yes
- User data per job 76Byte
consistent data 76Byte (for X_SEND or X_RCV)
64Byte (for X-PUT or X_GET as the Server)
Interfaces
Hardware description 1. interface
Physics RS 485
electrically isolated no
Interface power supply (15 up to 30V DC) 200mA
Functionality 1. interface
MPI yes
Profibus DP no
Point-to-Point connection no
MPI 1. interface
Services
- PG-/OP communication yes
- Global data communication yes
- S7 basis communication yes
- S7 Communication
as Server yes
as Client no
- Transmission rates 187.5kbit/s
Hardware description 2. interface
Physics RS 485
electrically isolated yes
Interface power supply (15 up to 30V DC) 200mA
Functionality 2. interface
MPI no
Profibus DP master yes
Profibus DP slave yes
Point-to-Point connection yes
- Transmission rate half duplex max. 115.2kbit/s
- Protocols
- ASCII
- STX/ETX
- 3964(R)
- USS
- Modbus Master
yes
yes
yes
yes
yes
Hardware description 3. interface
Physics RJ45
Functionality 3. interface
Profinet Ethernet
Services
- PG-/OP communication yes
continued ...
