Manual VIPA System 300S SPEED7 Chapter 4 Deployment CPU 313SC/DPM
HB140E - CPU SC - RE_313-6CF03 - Rev. 07/45 4-43
... continue
Event-ID Description
0xE400 Memory expansion MCC has been plugged
0xE401 Memory expansion MCC has been removed
0xE801 MMC-Cmd: CMD_START recognized and successfully executed
0xE802 MMC-Cmd: CMD_END recognized and successfully executed
0xE803 MMC-Cmd: WAIT1SECOND recognized and successfully executed
0xE804 MMC-Cmd: WEBPAGE recognized and successfully executed
0xE805 MMC-Cmd: LOAD_PROJECT recognized and successfully executed
0xE806 MMC-Cmd: SAVE_ PROJECT recognized and successfully executed
0xE807 MMC-Cmd: FACTORY_RESET recognized and successfully executed
0xE80B MMC-Cmd: DIAGBUF recognized and successfully executed
0xE80E MMC-Cmd: SET_NETWORK recognized and successfully executed
0xE8FB MMC-Cmd: Error: Initialization of the Ethernet PG/OP channel by means of
SET_NETWORK is faulty.
0xE8FC MMC-Cmd: Error: Not every IP-Parameter is set at SET_NETWORK.
0xE8FE MMC-Cmd: Error: CMD_START was not found
0xE8FF MMC-Cmd: Error: Reading the CMD file is faulty (MMC error)
0xE901 Check sum error
0xEA00 Internal error – Please contact the VIPA-Hotline!
0xEA01 Internal error – Please contact the VIPA-Hotline!
0xEA04 SBUS: Multiple parameterization of a I/O address
Zinfo1: I/O address
Zinfo2: Slot
Zinfo3: Data width
0xEA05 Internal error – Please contact the VIPA-Hotline!
0xEA07 Internal error – Please contact the VIPA-Hotline!
0xEA08 SBUS: Parameterized input data width unequal to plugged input data width
Zinfo1: Parameterized input data width
Zinfo2: Slot
Zinfo3: Input data width of the plugged module
0xEA09 SBUS: Parameterized output data width unequal to plugged output data width
Zinfo1: Parameterized output data width
Zinfo2: Slot
Zinfo3: Output data width of the plugged module
0xEA10 SBUS: Input address outside input area
Zinfo1: I/O address
Zinfo2: Slot
Zinfo3: Data width
continued ...
