Chapter 6 Deployment CPU 31x with TCP/IP Manual VIPA System 300V
6-50 HB130E - CPU - Rev. 11/50
Insert the following values and click on [Apply]:
Station name: CPU 31xNET (free chooseable)
Page frame basic address: 0 (fix)
Page frame number: 1 (fix)
Station address: 000000000000 (fix)
IP address (here 172.16.129.1) and Subnet mask (here 255.255.0.0):
The IP address and the subnet mask is available at your system
operator. The rest of the entries remain unchanged.
To configure the FETCH connection, you click on
. Insert the
following parameters and click on [Apply]:
Connection name: PC Fetch
Page frame offset: 0 (fix) Order type: FETCH passive
Order no: 1 Order model: Single order
Priority: 2
Port local: 7002 Port external: 7013
By setting an IP address for the foreign station you fix that the CP may
only contact this IP address. For a test environment you should leave
this field empty.
WRITE-passive connection
The project engineering of the WRITE connection is identical. Click on
, insert the following parameters and click on [Apply]:
Connection name: Receive from PC
Page frame offset: 0 (fix) Order type: Write passive
Order no: 2 Order model: Single order
Priority: 2
Port local: 7003 Port external: 7012
To transfer your WinNCS project you have the following two possibilities:
• Transfer directly via Ethernet
• Transfer via MMC
Basic CP
configuration
Configure
connection blocks
Transfer the
WinNCS project
FETCH-passiv connection (Read)
