Chapter 6 Deployment CPU 31x with TCP/IP Manual VIPA System 300V
6-52 HB130E - CPU - Rev. 11/50
WinNCS allows you to export your project as *.NCS file. Mark the station
and select
Export via the right mouse button. Assign the name
webcp.ncs to the file and transfer it to the MMC.
In the following description, the CP project is recognized due to the
unambiguous file name and transferred into the CP:
• Set the RUN-STOP switch of your CPU in position STOP.
• Turn off the power supply.
• Plug the MMC with the CP file into the CPU. Please take care of the
correct plug-in direction.
• Turn on the power supply.
• After a short start-up time, the alternately blinking of the LEDs SF and
FRCE shows that the CP file has been recognized on the MMC.
• You start the transfer of the file by tipping the RUN/STOP switch shortly
to MR within 10s.
• During data transfer, the LEDs SF, FRCE and MMC are blinking
alternately.
• The update has been completed successful when all CPU-LEDs are on.
At fast blinking, an error has occurred.
• Turn off the power supply, dismantle the MMC and switch on the power
supply again. CPU and CP are rebooting. Now the CP is at the network
with the configured IP address.
• Activate the online functions in WinNCS via
.
• Select "IP protocol" under
and type the new IP address
172.16.129.1.
• Establish a connection with
. Now you communicate with the IP
address given under CP-Init.
• The CP has to be in RUN. Proof this with
. If the CP is in Idle-
Mode, the synchronization with the CPU has failed. Please control the
SYNCHRON block in OB 100.
• For control you may monitor the summary status of the TCP
connections via
.
Transfer as
webcp.ncs
via MMC
Control the
WinNCS project
