SECTION 4: INSTALLATION REFERENCE 51
EPI800 Manual.doc EPI 800 MANUAL 2001 Vision Microsystems Inc.
FIGURE 7: Fuel Flow Transducer Orientation
PN: 3010019 Transducer Orientation (arrow
must point up after installation)
PN: 3010032, 3010035 Transducer Orientation
(wires must point up after installation)
