SECTION 4: INSTALLATION REFERENCE 52
EPI800 Manual.doc EPI 800 MANUAL 2001 Vision Microsystems Inc.
FIGURE 8: Amps Transducer Orientation
Pass monitored wire through AMPS transducer as shown with
current flow in proper direction.
TO
Aircraft Bus
TO
Alternator
Output
