APPENDIX A. Specifications
D-304762 PowerMaster-10/30 G2 Installer's Guide
75
PowerMaster-10 G2 PowerMaster-30 G2
Real Time Clock
(RTC)
The control panel keeps and displays time and
date. This feature is also used for the log file by
providing the date and time of each event
The control panel keeps and displays time and
date. This feature is also used for the log file by
providing the date and time of each event
Battery Test Once every 10 seconds Once every 10 seconds
A2. Wireless
PowerMaster-10 G2 PowerMaster-30 G2
RF Network PowerG – 2-way synchronized Frequency
Hopping (TDMA / FHSS)
PowerG – 2-way synchronized Frequency
Hopping (TDMA / FHSS)
Frequency bands
(MHz)
433 – 434 868 - 869 912 – 919* 433 – 434 868 - 869 912 – 919*
Hopping
frequencies
8 4 50 8 4 50
Region Worldwide Europe North
America and
selected
countries
Worldwide Europe North
America and
selected
countries
Encryption AES-128
Note: AES-128 bit encryption for
communication between control unit and
initiating devices is not suitable as a means of
Encrypted Line Security in UL Listed product.
AES-128
Note: AES-128 bit encryption for
communication between control unit and
initiating devices is not suitable as a means of
Encrypted Line Security in UL Listed product.
* For UL Listed product, enable this frequency band.
A3. Electrical
PowerMaster-10 G2 PowerMaster-30 G2
External AC/AC
adaptor
Europe: 230VAC 50Hz input, 9VAC 700mA
output.
USA: 120VAC 60Hz input, 9VAC 1000mA
output.
NA
External AC/DC
adaptor
NA External (wall-mounted) switching power
supply 100VAC to 240VAC, 50/60 Hz, 0.5A /
12.5 VDC, 1.2A
Internal AC/DC Internal switching power supply:
Input: 100-240VAC, 0.12 A Max.
Output: 7.5VDC, 1.2A Max.
Internal switching power supply:
Input: 100-240VAC, 0.5A
Output: 12.5 VDC, 1.6A.
Current Drain Approx. 240 mA standby at the beginning
(power ON) and then goes down to 90 mA
standby, 1200 mA peak at full load.
Approx. 260 mA standby at the beginning
(power ON) and then goes down to 60 mA,
1400 mA max. current drain during alarm.
Low Battery
Threshold
4.8 V 7.2 V (6-cell battery pack)
9.6 V (8-cell battery pack)
Backup Battery
Pack
4.8V 1300 mAh, rechargeable NiMH battery
pack, p/n GP130AAM4YMX, manufactured by
GP or equivalent.
4.8V 1800 mAh, rechargeable NiMH battery
pack, p/n GP180AAM4YMX, manufactured by
GP or equivalent (special order).
4.8V 2200 mAh, rechargeable NiMH battery
pack, p/n GP220AAM4YMX, manufactured by
GP only. For UL Listed product, use this
battery only.
Caution! Risk of explosion if battery is
replaced by an incorrect type. Dispose of
used batteries according to the
manufacturer's instructions.
Note: For compliance with CE standards the
battery capacitymust be at least 1300 mAh..
Backup Battery Options:
Maximum external devices current (1)
6 Battery
Pack (2)
1800 mAh
8-Battery
Pack (3)
2200 mAh
8-Battery
Pack (4)
4h 180 mA 300 mA 380 mA
24h max
backup w/o
load 22
hours
12 mA 25 mA
39h no backup 0 mA
(1) The external devices must be connected
between 12V and ground. The current for
each specified backup period can be
drawn from the batteries with the internal
GSM and the proximity reader connected
to the PowerMaster-30 G2.
