APPENDIX F. PowerLink3 IP Communicator,
D-304762 PowerMaster-10/30 G2 Installer's Guide
87
Hardware Installation
Step 1.
Open the control panel:
PowerMaster-10 G2
PowerMaster-30 G2
Step 2.
Mount the Internal PowerLink3 IP Communicator into the control panel and fasten it with 2 screws:
PowerMaster-10 G2
PowerMaster-30 G2
