69
ВАРШ.201219.009РЭ
Figure B.14 - Alarm Tab
Description of the Alarm tab is presented in Table B.5.1
Table B.5.1 - Buttons of the Alarm tab
Tab
Button
Description
Motion
Detection
Enable Motion
Detection
Check the box to enable motion detection
Onvif Motion
ActiveCells
Mode
Select a mode - standard or compatibility.
If you are using third-party motion detection software, set the
compatibility mode.
Set Motion Re-
gion
Indicate the area (s) of motion detection on the image using the
cursor.
Select All
Click the button, the motion in the area will be detected
Clear All
Click the button, the area drawn before will be removed
Sensitivity
Sensitivity level, 1~10
Schedule Set-
tings
Indicate operating time.
Alarm Action
Selecting a notification when an alarm is triggered.
Save into SD
card:
Select file format: AVI, JPG or both
Save Into
Storage
Select file format: AVI, JPG or both
Upload Via FTP
Select file format: AVI, JPG or both
Upload Via
SMTP
File format: JPG
External Output
If the camera equips with External Output, you can enable the
action after configuring the trigger duration
Play Audio
If the camera equips with Speaker, you can enable the action
after configuring the audio speaker
Alarm to SIP
Phone
Support to call the SIP phone after enable the SIP function
HTTP
Notification
Send HTTP event notification. Specify the URL, username and
password, example: http://ip:8601/Interface/Cameras/Mo-
tionDetection/Notify?Camera=CameraName
HTTP Name: admin (логин камеры)
HTTP Password: en123456 (пароль камеры)
Flashlight
Turns on the flashlight when an alarm event occurs. For PTZ
series camera only.
PTZ movement
When a motion detector is triggered, allows the camera to fol-
low the object.
Disables on-touch patrol. For PTZ series camera only.
Alarm actions
Selecting an action when alarm is triggered.
