DPU-00084

Revision 2.3

Page 12 of 39

3 Installation Overview

3.1 System Architecture

Figure 2: Adept Validator Typical System Architecture

3.2 Power Supply

Adept Validator can be powered either by Power-Over-Ethernet or by 24V DC power supply.

Table 3: Power Supply Specification

PARAMETER

MIN.

TYP.

MAX.

UNIT

Input Supply Voltage

Specified Input Current on power-up (@24V)

Specified Input Current steady state (@24V)

0.25 (6W)

0.35 (8.4W)

0.7 (16.8W)

Reverse Voltage Protection

-100
