Vix Assure Adept Validator User Manual

DPU-00084
Revision 2.3
Page 18 of 39
END TERMINATION
CABLE
ID
PIN NAME
PIN
ADEPT END
CONN
Molex # 39012040 + suitable
crimps
A
EXT_GPO_1
1
2
Molex #
5016462000
(Optional)
A
EXT_GPO_2
2
NC
EXT_IN_0V
3
NC
EXT_GPO_ISO
4
A
EXT_IN_H_1
5
A
EXT_IN_H_2
6
USB type A jack
D
USB_OTG_P
7
USB_OTG_ID
8
USB_OTG_N
9
GND
10
VBUS_OTG
11
DB9 female
E
DIAG_RX232 (Diagnostic RS232)
12
DIAG_TX232 (Diagnostic RS232)
14
DIAG_GND (Diagnostic RS232)
16
NC
GND
13
DB9 male
F
XCVR_GND
15
TXCR_A_B_P (Multiprotocol Txcr)
17
TXCR_A_B_N (Multiprotocol Txcr)
18
TXCR_Y_Z_P (Multiprotocol Txcr)
19
TXCR_Y_Z_N (Multiprotocol Txcr)
20
Select with the below
consideration in mind:
Interconnection introduces extra
loss
G
GPS
Centre
3
Amphenol #
3FA1ENZRJ-
C01ER
(Optional)
GPS_GND
Shield
5.2 Connector Termination
The design incorporates two robust Molex iGrid automotive connectors, that are easy to crimp large or small cables
using a variety of readily available crimps. There is also a FAKRA connector for models with GPS.
Figure 8: Adept Validator Rear Connectors
Pole-Mounted
Surface-Mounted
