DPU-00084

Revision 2.3

Page 35 of 39

Figure 33: Cradle Front and Rear Separation

5. Remove the cradle front by carefully pulling it out from the pole.

Note: Care must be taken not to damage the cables/connectors during cradle front removal.

Figure 34: Cradle Front Removal

Press

Pull
