25
Frame Rail
Insert, then R otate 90
o
Figure 14
7. Install the inner coupling nut on the inner side upper tank bracket in the same manner as with
the outer nut. Insert a long hex head cap screw into the bracket and thread it into the
coupling nut
8. Repeat these procedures with the rear tank bracket. When installed, they should appear
similar to Figure 15.
Emergency Brake Cable
Figure 15
