USING VOLTAGE AND CURRENT TRANSDUCERS
PM1000+ Power Analyzer User Manual © Voltech 2010 Page 11
2. QUICK START
2.1. POWER ON
1. Check the power analyser is in good condition with no signs of damage.
2. Connect the line power supply cable.
3. Ensure the supply is Earth grounded.
4. Press the power switch at the front to on (I)
The PM1000+ will start its power up sequence. This takes 5-10 seconds.
During power up you will see the PM1000+‟s serial number and last
adjustment date.
5. The instrument is now ready for use
