THE MENU SYSTEM
Page 36 © Voltech 2010 PM1000+ Power Analyzer User Manual
Auto Zero
Normally the PM1000+ will cancel any small dc offsets in the measurement
automatically. This is called Auto Zero.
Auto Zero should always be enabled.
Select Disable and Enable and press to confirm.
Clock Setup
These options may be used to check or set the PM1000+‟s internal clock.
To select a menu item, use the keys and then press for detailed options.
Set Time - Enter the time using the format shown and press OK to confirm.
Set Date - Enter the date using the format shown and press OK to confirm.
Time Format - Select 12 Hour or 24 Hour and press to confirm.
Date Format - Select the required date format and press to confirm.
Unit Configuration
For units with firmware version 4.13 or later, the Unit Configuration menu displays
the hardware revision, firmware revision, serial number, date and type of last
adjustment and whether IEC mode has been enabled. To meet the enhanced
specification for 45-65Hz, the adjustment type must be “enhanced”
IEC Key Code Entry
This is used to enable the IEC Pre-Compliance PC software. After the software
has been enabled, this menu item will be disabled.
The status of the IEC Pre-Compliance Software (Enabled or Disabled) can be
viewed in the Unit Configuration menu.
4.10. USER CONFIGURATION.
Save and recall your set up.
To select a menu item, use the keys and then press for detailed options.
The first option is to „Load Default‟. Choosing this option will set every menu
option of the PM1000+ to its factory default.
The other menu items (Default „CONFIGURATION n‟) may be used to store and
recall all settings of the PM1000+
