SPECIFICATION
PM1000+ Power Analyzer User Manual © Voltech 2010 Page 71
5 - 0V
6 - Open
7 - CTS (i/p)
8 - RTS (o/p)
9 - Open
AUX/TRIG
For Voltech Use Only.
GPIB
To IEEE488 standard.
USB Peripheral (USB Test and Measurement Class [USBTMC])
USB 2.0 compatible. Will work with any USB 2.0 system.
Full Speed (12Mbits/sec).
1 - VBus (i/p)
2 - D- (i/p and o/p)
3 - D+ (i/p and o/p)
4 - 0V (i/p)
For basic communication needs via USB peripheral, the user can try the Agilent
Connection Expert contained in the Agilent IO Libraries Suite 15.0.
