REMOTE OPERATION
PM1000+ Power Analyzer User Manual © Voltech 2010 Page 49
:SEL:VHM Add Voltage harmonics to the list.
Now, assuming :SEL:CLR has not been issued after example 1, then the following
results would be returned by :FRD?
Vrms, Arms, Freq, Watt, VA, Var, PF, Vpk+, Apk+, Vh1 Mag, Vh1 phase, Vh2 Mag,
Vh2 phase, …. Vh9 Mag, Vh9 phase.
Standby power
First, select standby power mode
:MOD:SBY:PER 60 Set the standby power mode period to 60 seconds.
:MOD:SBY
:SEL:CLR Clears selection of results
:SEL:VLT Selects Vrms
:SEL:WAT Selects Watts
:SEL:FRQ Selects Frequency
:SEL:VCF Selects Volts crest factor
:SEL:VDF Selects Volts distortion factor
:RNG:VLT:FIX 4 Fix the voltage range to 1000Vpk
:RNG:AMP:FIX 3 Fix the current range to 1.6Apk
Wait 60 seconds
:FRD? Read back values including average power over 60 seconds
Wait 60 seconds
:FRD? Read back value including average power over 60 seconds.
Check against previous power.
