Electrical System
System voltage 24V
AC generator:
voltage/max. amperage 28V/110A
output, approx. 2640W
Alternative generator equipment (accessory):
voltage/max. amperage 28V/110A
output, approx. 2640W
Alternative generator equipment (accessory):
voltage/max. amperage 14V/115A
output, approx. 1610W
Battery capacity 2 connected in series 12V, max. 220 Ah
Battery electrolyte density at +25°C (77°F)
fully charged battery
1.28 g/cm
3
= 0.0462 lb/in
3
(1.24 g/cm
3
= 0.0448 lb/in
3
)
(1)
battery recharged at
1.24 g/cm
3
= 0.0448 lb/in
3
(1.20 g/cm
3
= 0.0434 lb/in
3
)
(2)
1) Applies to batteries with tropical acid.
2) Applies to batteries with tropical acid.
Propulsion Unit
WARNING!
Use of other transmission oils than recommended may result in increased gear shifting delay and show other
handling characteristics than what you are used to with the factory filled Volvo Penta approved oil.
IMPORTANT!
For transmissions in the marine environment, it is extremely important that the correct transmission oil is used.
Using an incorrect transmission oil may very quickly affect transmission life and function. Extensive testing has
resulted in an oil developed to optimize the friction in clutch packages and maximize the lifetime for gears and
bearings. AB Volvo
Penta accepts no responsibility or liability for any damage or cost arising due to use of other
oils than recommended.
Oil capacity, approx. 30 liters
7.9 US gal
Oil volume difference MIN - MAX 0.5 liters
0.5 US quart
Oil quality VP 3809443 (liters)
VP 1141679 (US quart)
Gear ratio 1.99:1
Technical Data
132 47705796 05-2014 © AB VOLVO PENTA
