Volvo Penta IPS - Station Panel

Station Panel
Activation
Activate the
helm station with a single press of the but-
ton. Further pressure locks the helm station.
To render the helm station inactive, hold the button
down for 3 seconds.
Inactive helm station
Active helm station
Locked helm station
Low speed
For further information about the function, refer to
chapter Optional page 36.
Neutral button
The gearshift
function can be disconnected so that the
control lever only operates the throttle. The neutral
button disengages the drive/reverse gear so that
engine speed may be increased without driving the
boat; (warm-up mode).
The drive is disengaged.
Drive engaged for movement ahead/astern.
Single lever
When the single-lever function is activated, the lever
that is moved from its position first becomes the control
lever for both engines. The other control lever has no
function as long as the single-lever function is acti-
vated.
P0001088
Instruments and Controls
