Overview
The DPS view shows when the DPS function is acti-
vated.
If
you browse to another view, the DPS view will
be re-displayed after a brief period of inactivity.
1 Fuel level
2 GPS signal strength
3 Bearing
4 Direction of movement
5 DPS symbol
Activating the DPS
The DPS can only be activated when boat speed is
below 3 knots.
The function remains active for a maximum of 12
hours.
In order to engage the DPS, the warning message
shown when the engine is started must be acknowl-
edged. The message is acknowledged by pressing the
button or the knob on the control panel.
Activating the DPS at the main helm station
1 Make sure that swimmers and boats or other
objects are more than two boat lengths away.
2
Move the control levers to neutral.
3 Press the DPS button (1). An audible signal con-
firms that the DPS is active and the button light is
lit. The screen shows a brief warning message
before switching to the DPS image.
Activating the DPS at the docking station
1 Make sure that swimmers and boats or other
objects are more than two boat lengths away.
2 Press the DPS button (1). An audible signal con-
firms that the DPS is active and the button light is
lit.
MY VIEW
WARNING
PRESS TO
CUSTOMIZE
NW
NE
SE
SW
W
S
E
N
1 2 3 4 5
P0010264
WARNING:
When DPS in Use Boat is Underway
Maintain proper
LOOKOUT
STAY OUT of
water – spinning
propellers.
Failure to observe warnings may result in
SEVERE INJURY or DEATH.
ACCEPT
HOLD ON to
prevent falls – boat
can move suddenly
READ the
owner’s manual
P0010268
Warning message at start
Optional
50 47705796 05-2014 © AB VOLVO PENTA
