VTech CS6114 User Manual

18
Telephone operation
Directory
The directory can store up to 30 entries (including 10 speed
dial entries). Each entry may consist of a phone number up
to 30 digits and a name up to 15 characters.
Each handset directory is independent of the other
handsets. Directory entries are shared by all system
handsets. Any additions, deletions or edits made on one
JCPFUGVYKNNPQVDGTGƀGEVGFKPVJGFKTGEVQT[QHQVJGT
handsets.
When there are no records in the directory, the screen
shows Directory empty.
When the directory is full and you try to save an entry, the
screen shows Directory full.
If you try to save an entry already stored in the directory,
the screen shows Number repeated.
If the telephone number in the directory exceeds 15
digits, - appears after the 14th number and the rest of the
numbers will be shown two seconds later on the same
row beginning with a -.
Only one handset can review the directory at a time. If a
handset tries to enter the directory while another handset
is already in it, Not available appears.
•
•
•
•
•
•
Directory empty
Directory full
Number repeated
Not available
Elizabeth Jones
18001234567890-
Elizabeth Jones
-1234567890123-
Elizabeth Jones
-456

VTech CS6114 Specifications

Frequency

transmit frequency handset	1921.536-1928.448 MHz
transmit frequency telephone base	1921.536-1928.448 MHz

Power

power requirements handset	2.4V 400mAh Ni-MH battery
power requirements telephone base	6V AC @ 300mA
power requirements charger	6V AC @ 300 mA

Memory

handset directory	30 memory locations; up to 30 digits and 15 characters
handset call log	30 memory locations; up to 24 digits and 15 characters

Weight and Dimensions

size handset	6.50 X 2.0 X 1.26 in (165.0 X 51.0 X 32.0 mm)
size telephone base	3.55 X 3.44 X 4.67 in (90.2 X 87.5 X 118.5 mm)
size charger	2.91 X 3.19 X 1.85 in (74.0 X 81.0 X 47.0 mm)
weight handset	4.59oz (130.0g)
weight telephone base	4.32oz (122.6g)
weight charger	1.76oz (50.0g)
