IVTM
4
Components
17
Depending on rim crank, use of the normal module according to Figure 4-1 or the
called L-shape or T-shape version is recommended. For details see Table 4-1
d also the chapter on configuration (see chapter 3.3, page 10 and see chap-
so-
an
ter 3.3, page 10).
Application WABCO
number
Hole, wheel
bolt
Bolt circle
Ø
Angle Figure
Trailer: Independent wheel (no Super-Single) 960 731 011 0 26 mm 335 mm 0°
Trailer: Independent wheel (no Super-S
special purposes (e.g. Iveco)
ingle), 20° for 960 731 013 0 23 mm 335 mm 0°
Trailer: Independent wheel (no Su
pitch circle diameter
0° per-Single), 23 mm 960 731 017 0 23 mm 335 mm
Trailer: Independent wheel (no Super-Single) 960 731 021 0 32 mm 335 mm 0°
Twin tires, Super-Single 960 731 031 0 26 mm 335 mm 70°
Twin tires, Super-Single 960 731 041 0 32 mm 335 mm 70°
Towing vehicle: Front axle, load axle 960 731 051 0 26 mm 335 mm 60°
Towing vehicle: Front axle, load a 335 mm 0° xle 960 731 053 0 32 mm
Towing vehicle: Front axle, load a 960 731 055 0 26 mm 335 mm 60° xle
