WABCO TEBS E - Page 106

6
TEBS E GIO functions
106
Components
Component Figure Part number
Horn/Rotary beacon Not part of WABCO's
scope of supply
SmartBoard (optional)
Display for warnings
446 192 11. 0
Cable for SmartBoard (optional) 449 911 ... 0
Trailer Remote Control (optional)
Only in combination with ELEX and version
TEBS E2 or higher.
Warnings are indicated in two warning stages.
Connecting cable between Trailer Remote Control
and fuse box in the truck and a bracket are in-
cluded in delivery.
446 122 080 0
Buzzer (optional) 894 450 000 0
Warning lamp (optional)
Proximity switch (optional)
Parameter setting
Activation and function settings are done via tab 8, General functions.
An additional warning lamp is controlled by means of a freely configurable digital
function. An internal Tilt warning (Tilt Alert) active input signal is selected for this
purpose.
The GIO slots to use are defined in tab 11, connector.
