6.13 Speed signal
Vehicle type
All trailer vehicles
Purpose
In addition to the ISS speed switch, which only outputs switch settings, TEBS E
can provide a speed signal for evaluation by the connected systems, e.g. for con-
trolling steering axles or for closing tank covers.
Function
The TEBS E Modulator provides a speed signal in the form of a pulse-width modu-
lated rectangular signal.
Components
Component Part number
Universal cable
4-pin, open
Cable colours:
red = pin 1 (v signal)
brown = pin 2 (ground)
yellow/green = pin 3
blue = pin 4
449 535 ... 0
Parameter setting
The function is activated via tab 8, General functions.
The GIO slots to use are defined in tab 11, connector.
