TEBS E Appendix
212
12.5 Brake diagram
Brake diagram
Open the WABCO website http://www.wabco-auto.com
.
Here click on Product catalogue INFORM.
Click the link Index.
Enter Wiring diagram in the Index field.
Click on the Start button.
Select Wiring diagram.
Click the link Product search.
Click the link Application.
Click on Trailer EBS E.
Semitrailer
Axle(s) ABS
system
Number Tristop Overload protec-
tion valve
PEM Lifting
axle(s)
Mechanical
suspension
Additional
trailer
PREV Comment
1 2S/2M 841 701 180 0 x x x
1 2S/2M 841 701 181 0 x x x
Dolly / hydraulic
suspension
1 2S/2M 841 701 182 0 x x x
1 2S/2M 841 701 183 0 x x x 12 V
2
2S/2M
4S/2M
841 701 190 0 x x x
2 4S/3M 841 701 191 0 x x x
2 2S/2M 841 701 192 0 x x
2
2S/2M
4S/2M
841 701 193 0 x x x
2 4S/3M 841 701 195 0 x x x Only one axle Tristop!
2 4S/3M 841 701 196 0 x x x
2
2S/2M
4S/2M
841 701 197 0 x x x x
2
2S/2M
4S/2M
841 701 198 0 x x x one Tristop separately
3 4S/3M 841 701 050 0 x x
3 4S/3M 841 701 055 0 x CAN-Repeater
3 4S/3M 841 701 057 0 x x x
CAN-Repeater +
Select Low
3 4S/3M 841 701 058 0 x x x CAN-Repeater
3
2S/2M
4S/2M
841 701 100 0 x
