8.6 Installation of Immobilizer components
Installation
– Install the immobilizer according to diagram 841 701 227 0, see chapter 12.5
‘Brake diagram’, page 212.
–
Pay attention to the information on the proposal drawing 463 084 100 0 when
installing the pulse-controlled lifting axle valve.
Proposal drawing for immobilizer
Open the WABCO website http://www.wabco-auto.com
.
Here click on Product catalogue INFORM.
Enter 463 084 100 0 in the Product Number field.
Click on the Start button.
Click the Publications radio button.
The lifting axle valve can be connected to GIO2 or GIO3.
The lifting axle valve can be connected to GIO1, GIO2 or GIO3.
8.7 Installation of Trailer Remote Control
Please refer to the documents ‘Trailer Remote Control – Installation and connec-
tion instructions’, see chapter 4 ‘Introduction’, page 12 => Se
ction ‘Further informa-
tion’ for a detailed description of Trailer Remote Control installation and connection.
