6
TEBS E
GIO functions
114
Connecting the components
Legend
A
Optional switch for locking the
steering axle
B
(+) signal from the reversing lamps
The diode is no longer required with TEBS E4
or higher.
Parameter setting
The function is activated via tab 8, General functions.
The GIO slots to use are defined in tab 11, connector.
