TEBS E
11
Workshop notes
189
Repair Kits
The table below shows a selection of the most important repair kits at a glance:
Repair kit Part number
Replacement of TEBS E connector fuses on the ECU 480 102 931 2
Replacement of the modulator couplings 480 102 933 2
Replacement of the PEM for fastening and sealing (set of seals)
Can be used for plastic and aluminium PEM
461 513 920 2
Replacement of the PEM (without couplings) 461 513 002 0
Replacement of the pressure sensor 441 044 108 0
EBS relay valve (set of seals) 480 207 920 2
Replacing an ABS speed sensor 441 032 808 0 441 032 921 2
Replacing an ABS speed sensor 441 032 809 0 441 032 922 2
Removing the pipes from the New Line couplings 899 700 920 2
Repair Aluminium-PEM 461 513 921 2
Repair plastic PEM 461 513 922 2
Tightening torques
Use these tightening torques when replacing valves, plug-in connectors, etc.
For details on pipe threads, see DIN EN ISO 228.
Thread Maximum tightening torque
M 10x1.0 18 Nm
M 12x1.5 24 Nm
M 14x1.5 28 Nm
M 16x1.5 35 Nm
M 22x1.5 40 Nm
M 26x1.5 50 Nm
Publications
Detailed information on the topics of exchange, repair and couplings can be found
in our catalogues, see chapter 4 ‘Introduction’, page 12 => Sectio
n „More Informa-
tion’.
