5
TEBS E
braking system
30
Components / Part number Application / Vehicle type Purpose/Function
Park Release Emergency Valve
(PREV)
971 002 900 0 (M 16x1.5; with plate)
971 002 902 0 (M 16x1.5)
971 002 910 0 (ø8x1, with pressure test
connection)
971 002 911 0 (2x ø10x1; 3x ø8x1)
971 002 912 0 (ø8x1, with plate and
pressure test connection)
971 002 913 0 (2x ø10x1; 3x ø8x1)
All trailer vehicles Functions of the trailer brake valve and
the double release valve combined in
one unit (including emergency brake
function).
Select Low Valve
(Double cut-off valve)
434 500 003 0
Vehicles with 2S/2M+Select Low con-
trol, e.g. with steering axle.
The input pressures are the pressures
output by the trailer modulator for each
side. The lower pressure is directed to
the axle to be braked.
Select High Valve
(Double check valve/Two-way valve)
434 208 055 0
Vehicles with 4S/2M+1M system for
actuating the separate ABS relay valve.
The input pressures are the pressures
output by the trailer modulator for each
side. The higher pressure is fed to the
ABS relay valve.
ABS rotational speed sensors
441 032 808 0 (0.4 m)
441 032 809 0 (1 m)
On the brake mounts of the axles or the
main axles.
Detection of the movement status of a
rotating pole wheel together with the
vehicle wheel.
Pressure sensors
441 044 101 0
441 044 102 0
On one of the support bellows of the
axle to be monitored.
On the yellow coupling head.
Axle load measurement.
Measurement of pressure at the yellow
coupling head.
