Before Installation
4.3 Best Practices in Installation
DANGER
Vehicle electrical grounding guidelines are included in Appendix I.
4.3.1 Assembly
The assembly of the parts must be done using the accessories provided. ZF cannot be held responsible
for any errors resulting from the use of other materials. ZF wishes to point out that activities which require
welding to the trailer, can cause damage to the electronics of the device. It is imperative that the device is
disconnected when carrying out such activities.
4.3.2 Wire Management
All the wire ways shall be smooth and free from sharp edges. Wires shall be protected, so they do not come
conductors.
4.3.3 Operating Conditions
Input voltage range: 10 - 32 V
Maximum current: 1.5 A
Operating temperature range – Externally powered -40°C ~ +75° C
Operating temperature range – Battery powered: -20°C ~ +60° C
Battery charging temperature range: 0°C ~ +45° C
Storage temperature range – Battery powered: -20°C ~ +60° C
Nominal power consumption – Battery fully charged: 0.6 W
Maximum power consumption – Battery charging: 7.5 W
Ingress protection: IP6K6K/IP6K9K
Compliance with: ISO 16750 – D/E – L – E - D - D – IP6K6K / IP6K9K
