WABCO RSS Subsystems
11 WABCO RSS Subsystems
11.1 Hardware Connection
In case of RSSplus 2M (480 107 001 0) modulator, you can connect TRAILERCAST with Battery to the
modulator SUBSYSTEMS port using the RSSplus adapter cable (449 913 050 0) and TRAILERCAST
connection cable (894 600 001 2).
G105
G104
GENERIC IN/OUTPUTS
G103
G102
G101
ABS-
f /G106
ABS-
d
MODULATOR
POWER
SUBSYSTEMS
IN/OUT
G107/ABS- e
ABS- c
4019863b
RSSplus 480 107 001 0
Conguration Cable(s) Connections iABS port
1. RSSplus 449 913 050 0
Subsystems
G105
G104
GENERIC IN/OUTPUTS
G103
G102
G101
ABS-
f /G106
ABS-
d
MODULATOR
POWER
SUBSYSTEMS
IN/OUT
G107/ABS- e
ABS- c
4019863b
2. TRAILER-
CAST with
Battery
894 600 001 2
