Introduction - Hardware Components
5 Introduction - Hardware Components
TRAILERCAST with Battery is a trailer tracking device with an embedded SIM card, GSM antenna and
GPS antenna. It is designed for outside use. It has an RF antenna to be used for tire pressure monitoring.
It is designed to be installed under the trailer. TRAILERCAST with Battery connects to the trailer’s iABS or
RSSplus.
TRAILERCAST UNIT DIMENSIONS (L x W x H)
(Cf. Section 7 Fastening TRAILERCAST with Battery,
page 20)
Installation Bracket
In case the installation includes a TPMS system (with
internal sensors), an installation bracket must be used to
used, the installation brackets are not required.
Bracket Dimensions: 251.8 x 205 x 4 mm
Hardware Description: Front view
4019844c
iABS/RSSplus PORT
FIXING
POINTS
Back view
AIR VENT
CF. NOTE
NOTE: Make sure that the air vent of the TRAILERCAST
with Battery unit is always accessible to air. Make sure
that nothing can block the air access of the air vent. (DO
NOT apply glue/tape/silicone along the edges of the unit.)
Mounting the unit on any bracket should not block the air
vent.
