Installation – TRAILERCAST with Battery Position
6 Installation – TRAILERCAST with Battery Position
6.1 General Recommendations
When installing TRAILERCAST with Battery, keep the area around the antennas away from metal or
other obstructions as much as possible to avoid signal disturbance.
the unit with a ZF technician before deploying on a large scale.
Verify the installation with an external power source connected to the TRAILERCAST with Battery unit.
To obtain a full battery capacity, connect the TRAILERCAST with Battery unit to an external power
source for 4 hours.
Make sure that the unit will not be continuously exposed to direct sunlight.
Make sure that the label of the unit is always visible.
The installation technician remains responsible at all times for the correct installation and connection of
the hardware unit.
has been received via . Check this for every
installation.
6.2 Preferred Installation (Standard Trailer with Fixed Trailer Bed)
In case the installation includes a Tire Pressure Monitoring System (TPMS) system (connecting to the
The unit must be installed below the trailer bed with the front of the TRAILERCAST with Battery unit
directed to the ground.
Make sure that the front of the unit has a clear view to the ground (not obstructed by other components).
Keep the sides of the unit at a minimum distance of 20 cm from obstacles.
using (Section 14 Checking the Installation,
page 38).
