Connecting Hardware
1. Plug the connector into the port. The design of the connector will help prevent you from plugging it in
incorrectly.
4019857a
2. Press down the connector. By pressing down the connector, the yellow clip will automatically move
down.
4019858a
3. Finally, press the yellow clip to lock the connection. A distinct “click” should be heard.
4019859a
