RD 12/RD 12A Disassembly & Assembly
wc_tx000671gb.fm 113
Continued from the previous page.
7. Loosen the hose clamps that secure the hydraulic hoses (d and e) to the drive and
exciter pumps.
8. Pull the hydraulic tank from the hydraulic hoses (loosen the fittings if necessary) and out
of the frame.
The procedure to remove the hydraulic tank is now complete.
wc_gr004206
d
e
