Operation RD 12/RD 12A
wc_tx000865gb.fm 30
2.6 Stopping/Parking
See Graphic: wc_gr002953
2.6.1 Stop the machine on a flat surface with a suitable load bearing
capacity.
2.6.2 Turn the vibration off by pressing the vibration control button (10) on
the forward/reverse lever (15).
2.6.3 Press the water spray switch to the OFF position (61).
2.6.4 Set the forward/reverse control (15) to the NEUTRAL position.
2.6.5 Return the engine throttle to idle by pressing the lower half of the
throttle switch (54) and allow the engine to cool down.
2.6.6 Set the parking brake (42). To set the parking brake, pull the brake
lever up until the brake pad engages the drum. To release the brake,
lower the brake lever. Always set the parking brake before leaving the
machine.
Note: The parking brake engages the rear drum only.
2.6.7 Stop the engine by turning the ignition switch (55) to the OFF position.
If the vehicle constitutes a hazard or obstacle to traffic when parked, it
should be marked with signs, lights, and other warnings.
If the machine must be parked on a sloping surface, chock the drums
with wedges to prevent any vehicle movement.
WARNING
wc_gr002953
N
F
R
61
42
10
15
55
54
