Wacker Neuson 0620320

Disassembly & Assembly RD 12/RD 12A
wc_tx000671gb.fm 92
Continued from the previous page.
5. Using Loctite 243 on the six screws (e), secure the bearing cover (f) and the shock
mount plate (g) to the drum support. Torque the screws to 50 Nm (36 ft.lbs.).
.
The procedure to install the exciter is now complete.
wc_gr004167
g
f
e
