Disassembly & Assembly RD 12/RD 12A
wc_tx000671gb.fm 98
Continued from the previous page.
5. Remove the screws (e) that secure the control lever assembly (f) and remove the con-
trol lever assembly from the machine.
6. Disconnect the control cable (a) from the control lever assembly.
The procedure to remove the control cable and the control lever is now complete.
wc_gr004191
e
f
a
To Next Page
