3-20 BA ET18, 20, 24 en* 1.5 * et18_20_24e300.fm
3 Introduction
Meaning (option)
Check before starting the machine the operating pattern that has been
chosen. Label shows the lever position in which the ISO or SAE controls
are selected.
Position
At the left under the operator seat.
Meaning (option)
Indicates the control operations that do not comply with the ISO standard
if the SAE controls are selected.
Position
On the roof window on right in travel direction.
Meaning
Thermal stability of coolant.
Position
In the engine compartment on the expansion tank.
Fig. 38ISO/SAE changeover
Wiring diagram Controls
AISO controls
B SAE controls
Fig. 39SAE function label
