BA ET18, 20, 24 en* 1.5 * et18_20_24i400.fm 4-37
Putting into operation 4
Operation checklist
After starting the engine and during operation, check and observe the
following points:
Parking checklist
Check and observe the following points when parking the machine:
No. Question Page ✔
1
Anyone in the danger zone of the machine? --
2
Indicator light for engine oil pressure and alternator
charge function gone out?
4-32
3
Coolant temperature of engine in normal range? 4-34
4
Do the pedals and control levers work correctly? 5-13
5
Performed functional check of control lever base? 4-17
6
Telescopic travel gear extended? 5-23
No. Question Page ✔
1
Attachment lowered to the ground?
5-41
5-46
2
Stabilizer blade lowered to the ground? 5-21
3
Control lever base raised? 4-17
4
Cabin locked; particularly if the vehicle cannot be
supervised?
4-2
When parking on public roads:
5
Machine appropriately secured?
Machine additionally secured with chocks under the
tracks to prevent it from rolling away?
5-8
When parking on slopes:
6
Machine additionally secured with chocks under the
tracks to prevent it from rolling away?
5-8
