RD 12/RD 12A Disassembly & Assembly
wc_tx000671gb.fm 115
Continued from the previous page.
5. Connect the lanyard (g) and the air cylinder (h) to the hydraulic tank.
6. Connect the three hydraulic lines (a).
7. Fill the hydraulic tank. See section Changing Hydraulic Oil and Filter.
The procedure to install the hydraulic tank is now complete.
wc_gr004205
a
g
h
To Next Page
