Disassembly & Assembly RD 12/RD 12A
wc_tx000671gb.fm 68
9 Disassembly & Assembly
9.1 Tools Required for Disassembly/Assembly Procedures
It is up to the mechanic to use common sense and good judgment in tool
selection to reduce the risk of injury while repairing the machine.
In cases where a special tool is required, the special tool is listed in the
prerequisite section of the procedure.
Before substituting another tool or procedure from those recommended in this
manual, the mechanic must be satisfied that neither personal injury nor
damage to the machine will result due to the substitution.
9.2 Information Regarding Replacement Parts
The repair procedures contained in this manual do not include part numbers.
For replacement parts information, refer to the Parts Book originally supplied
with the machine.
If the original Parts Book has been lost, a replacement may be ordered from
Wacker Neuson Corporation.
When ordering a replacement Parts Book, please list the model number, item
number, revision level, and serial number of the machine.
Parts Books are also available on the Wacker Neuson Corporation Web site.
See www.wackerneuson.com. Enter the site as a visitor.
9.3 Information Regarding Reference Numbers ( )
Repair procedures contain reference numbers enclosed in parentheses ( ). These
numbers refer to the item numbers shown on the assembly drawings and other
detailed drawings. They are included to aid the mechanic in identifying parts and
assembling components.
9.4 Information Regarding Threadlocking Compounds
Background Due to the heavy vibration inherent in this type of equipment, the repair and service
procedures described in this manual specify the use of threadlocking compounds.
These compounds should be used where indicated to prevent the fasteners from
becoming loose.
Recommended
threadlockers
Although Loctite® is referred to throughout this manual, any equivalent type of
sealant such as Hernon®, Prolock, or Omnifit may be used. For a complete list of
recommended sealing and locking compounds, refer to the Use of Threadlockers
and Sealants chart at the end of this manual.
Applying
threadlockers
Clean the screw threads and wipe off any oil or grease before applying a thread-
locking compound.
